General Information

ADI Part Number

311322801

Brand Name

Hikvision

Manufacturer

Hikvision

Manufacturer Part Number

DS-2CD2955G0-ISU(1.05mm)

Product Line

Pro Series(EasyIP)

Product Model

DS-2CD2955G0-ISU

Product Name

5MP Fixed Fisheye Network Camera

Product Series

EasyIP 3.0

Product Type

Network Camera

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

5MP

Field of View

Horizontal: 180°, Vertical: 180°, Diagonal: 180°

HD Recording

Yes

Lens Mount Type

M12-Mount

Lens Type

Fixed

Maximum Aperture

f/2.25

Maximum Frame Rate

30 fps

Night Vision

Yes

Night Vision Type

Infrared

Wide Dynamic Range

Yes

Camera

Night Vision Distance

8 m

Certifications

RoHS Compliant

Compliant

Display & Graphics

Color Supported

Colour

Maximum Video Resolution

2560 x 1920

Environmental Conditions

Maximum Operating Temperature

50°C

Minimum Operating Temperature

-10°C

Operating Humidity

95%

Exposure

Longest Shutter Speed

1/3 Second

Minimum Illumination

0.017 lux

Shortest Shutter Speed

1/100000 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Focal Length

1.05 mm

Lens Included

Yes

Maximum Focal Length

1.05 mm

Physical Characteristics

Depth

41.2 mm

Form Factor

Fisheye

Weight (Approximate)

320 g

Power Description

Input Voltage

12V DC

Product Information

Diameter

119.9 mm

Mount Type

Ceiling Mount, Table Mount, Wall Mount

Storage

Storage Type

Memory Card

Video

Horizontal Resolution

2560

Miscellaneous

Environmental Certification

RoHS

Environmentally Friendly

Yes

Features

3D Digital Noise Reduction, Audio Compression, Back Light Compensation (BLC), Built-in Microphone, Day/Night, Motion Detection, Password Protection, Region of Interest, Tampering Alarm, Wide Dynamic Range

Hikvision DS-2CD2955G0-ISU(1.05MM) Pro Series 5MP Fixed Fisheye IP Camera, 1.05 mm Fixed Lens, WDR
