General Information

ADI Part Number

TI-PG62

Brand Name

TRENDnet

Manufacturer

TRENDnet

Manufacturer Part Number

TI-PG62

Product Line

Industrial

Product Model

TI-PG62

Product Name

6-Port Hardened Industrial Gigabit PoE+ DIN-Rail Switch

Product Type

Ethernet Switch

Technical Information

Media Type Supported

Twisted Pair

Power Consumption

5.76W

Certifications

NDAA Compliant

Yes

RoHS Compliant

Compliant

TAA Compliant

Yes

I/O Expansions

Expansion Slot Type

SFP

Number of SFP Slots

2

Number of SFP+ Slots

2

Number of Total Expansion Slots

2

Interfaces/Ports

Port/Expansion Slot Details

6 x Gigabit Ethernet Network

Total Number of Network Ports

6

Media & Performance

Network Technology

1000Base-T

Network & Communication

Ethernet Technology

Gigabit Ethernet

Networking Standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Physical Characteristics

Depth

228.6 mm

Form Factor

Rail Mount

Height

76.2 mm

Material

Metal

Weight (Approximate)

848.2 g

Width

177.8 mm

Power Description

Input Voltage

12V DC, 24V DC, 48V DC

Plug/Connector Type

Terminal Block

PoE Budget

60W

Power Source

Power Supply

Redundant Power Supply Supported

Yes

Product Information

Length

142.2 mm

Warranty

Limited Warranty

Lifetime Warranty

Miscellaneous

Environmental Certification

CE, Freefall (EN 60068-2-32), Shock (EN 60068-2-27), Vibration (EN 60068-2-6)

Features

1 x dedicated SFP slot, 1 x shared Gigabit port (RJ-45 / SFP), 12 Gbps switching capacity, 120 Watt power budget, 4 x Gigabit PoE+ ports, Alarm output triggered by power failure, Dual redundant power inputs with overload current protection, Extreme -40 to 75 ºC (-40 to 167 ºF) operating temperature range, Hardened IP30 rated metal switch, Includes wall and DIN-rail mounts

Package Contents

TI-PG62B
Quick Installation Guide
Removable terminal block
DIN-rail and wall mount kit

TRENDnet TI-PG62 6-Port Industrial Gigabit PoE DIN-Rail Switch 100 - 240 V AC, 50/60 Hz, 2 A , 12Gbps
