Name: Pyronix KX15DC-WE Enforcer Two-Way Wireless Digital Curtain Detector, Grade 2, 15m Range
Brand: Pyronix
SKU: KX15DC-WE

Pyronix KX15DC-WE Enforcer Two-Way Wireless Digital Curtain Detector, Grade 2, 15m Range

Brand: Pyronix

ADI #:KX15DC-WE Model #: KX15DC-WE Name: Pyronix KX15DC-WE Enforcer Two-Way Wireless Digital Curtain Detector, Grade 2, 15m Range

15m digital curtain detector
Enforcer two-way wireless technology
Digital temperature compensation

Pyronix KX15DC-WE 15M Enforcer Two-way Wireless Digital Curtain Detector, Grade 2

Product Overview

General Information

The KX15DC-WE gives curtain PIR coverage of any corridor or long area in front of windows or doors.

Two-Way Wireless Technology

Each wireless device on the Enforcer system, including movement detectors, is a transmitter and a receiver. The wireless technology used on the Enforcer system holds a significant advantage over one way and some two way wireless products currently available on the market.

Instant Two Way Device Control (ITDC)

The ITDC technology enables instant wake up and instant sleep of each device on the system, allowing continuous communication between the control panel and wireless devices while preserving battery power. This technology not only provides installers with total control of each device, but also gives users peace of mind that they have a reliable and secure wireless system.

- Ensuring that all wireless detection devices know when the system is armed and disarmed.

- Ensuring that they are awake as soon as the system is armed.

Signal Strength Indicator (SSI)

One of the key advantages of implementing of the SSI technology is to allow the installer to view the wireless transmission signal strength on both the control panel and wireless devices in real time.

Sealed optics

Protects from possible infestation from insects, shields air movement in front of the pyro-electric sensor and protects against adverse reflections from inside the detector housing.

ABS plastics 3mm

Polished finish, reduces electrostatic interference on the PIR sensor.

Blue wave technology

This technology further enhances the detector's immunity to infra-red noise in the environment. BWT comprises of some key components:

The new 3D optics system enables perfect focussing of the infra-red signal onto the pyro-electric sensor. This allows BWT to clearly identify the positive and negative signal edges.

Digital temperature compensation digitally adjusts the detectors sensitivity to maintain performance.

Powerful software embedded into a microprocessor is used to process the received information from the pyro-electric sensor. The result of this combination is lower infra-red signal noise amplification and therefore better immunity.

Main Features

15m digital curtain detector
Enforcer two-way wireless technology
Digital temperature compensation
Blue Wave technology
Sealed optics
Electrostatic-reducing ABS plastic housing, 3mm
Signal Strength Indicator
Complies with EN50131-1
Complies with EN50131-1

Information

Category : Intrusion, Motion & Perimeter Sensors, PIR Motion Sensors, Products, Smart Home, Smart Motion & Perimeter Sensors, Wireless Intrusion

Specifications

General Information

ADI Part Number

KX15DC-WE

Brand Name

Pyronix

Manufacturer

Hikvision

Manufacturer Part Number

KX15DC-WE

Product Model

KX15DC-WE

Product Name

KX15DC-WE Motion Sensor

Product Type

Motion Sensor

Technical Information

Connectivity Technology

Wireless

Maximum Motion Sensing Distance

15 m

Maximum Viewing Angle

20°

Passive Infrared Sensor (PIR)

Yes

Certifications

Security Grade

TAA Compliant

Physical Characteristics

Application/Usage

Art Gallery, Museum

Color

Blue, Red

Depth

50 mm

Height

117 mm

Width

69 mm

Power Description

Input Voltage

3V DC

Power Source

Battery

Product Information

Mount Type

Ceiling Mount, Wall Mount

Warranty

Limited Warranty

2 Year

Miscellaneous

Features

Bluewave Technology, Digital Curtain Detector, Digital temperature compensation, Sealed Optics, Signal Strength Indicator, Two-Way Wireless Technology
