General Information

ADI Part Number

ICX8200-C08PF

Brand Name

Ruckus

Manufacturer

Broadcom Corporation

Manufacturer Part Number

ICX8200-C08PF

Product Name

ICX 8200 Ethernet Switch

Product Series

ICX 8200

Product Type

Ethernet Switch

Technical Information

Media Type Supported

Optical Fiber, Twisted Pair

Certifications

RoHS Compliant

Compliant

TAA Compliant

Yes

I/O Expansions

Expansion Slot Type

SFP+

Number of SFP+ Slots

2

Number of Total Expansion Slots

2

Interfaces/Ports

Network (RJ-45)

Yes

Port/Expansion Slot Details

2 x 10 Gigabit Ethernet Expansion Slot, 8 x Gigabit Ethernet PoE+

Total Number of Network Ports

8

Uplink Port

Yes

Management & Protocols

Manageable

Yes

Media & Performance

Network Technology

10/100/1000Base-T, 10GBase-X

Network & Communication

Ethernet Technology

10 Gigabit Ethernet, Gigabit Ethernet

Layer Supported

3

Networking Standards

IEEE 802.1ab, IEEE 802.1ax, IEEE 802.1br, IEEE 802.1d, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE802.3af

Physical Characteristics

Color

White

Depth

213.9 mm

Form Factor

DIN Rail Mount, Rack Mount, Wall Mount

Height

4394.2 mm

Weight (Approximate)

2.27 kg

Width

270 mm

Power Description

Input Voltage

120V AC, 230V AC

Plug/Connector Type

C14

PoE (RJ-45) Port

Yes

PoE Budget

124W

Power Source

AC, PoE+, Power Supply

Warranty

Limited Warranty

Lifetime

Miscellaneous

Environmental Certification

EU RoHS, EU WEEE, REACH

Environmentally Friendly

Yes

Features

Fanless

Package Contents

ICX 8200 Ethernet Switch
3 x Years Remote TAC Support Included With Every ICX 8200 Model
Limited lifetime Warranty

Ruckus ICX 8200-C08PF 8-Port Compact POE Switch, White
