General Information

ADI Part Number

301802029

Brand Name

Hikvision

Manufacturer

Hikvision

Manufacturer Part Number

DS-3E1510P-SI

Product Line

Smart Managed Series

Product Model

DS-3E1510P-SI

Product Name

8 Port Gigabit Smart PoE Switch

Product Series

Smart Managed Gigabit PoE SI Series

Product Type

Network Switches

Technical Information

Media Type Supported

Optical Fiber, Twisted Pair

Power Consumption

120W

Certifications

RoHS Compliant

Compliant

I/O Expansions

Expansion Slot Type

SFP (mini-GBIC)

Number of SFP Slots

2

Number of Total Expansion Slots

2

Interfaces/Ports

Modular

Yes

Network (RJ-45)

Yes

Port/Expansion Slot Details

2x SFP, 8x 1Gbps

Total Number of Network Ports

8

Uplink Port

Yes

Management & Protocols

Manageable

Yes

Media & Performance

Network Technology

1000Base-T, 1000Base-X

Network & Communication

Ethernet Technology

Gigabit Ethernet

Layer Supported

2

Networking Standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Physical Characteristics

Depth

27.8 mm

Height

27.8 mm

Material

Metal

Weight (Approximate)

1.21 kg

Width

217.6 mm

Power Description

Input Voltage

48V DC

PoE (RJ-45) Port

Yes

PoE Budget

110W

Power Source

Power Supply

Miscellaneous

Environmental Certification

RoHS

Environmentally Friendly

Yes

Hikvision DS-3E1510P-SI Smart Managed Series, 8-Port Gigabit Smart POE Switch
