General Information

ADI Part Number

QNE-C8013RL

Brand Name

Hanwha Vision

Manufacturer

Hanwha Group

Manufacturer Part Number

QNE-C8013RL

Product Model

QNE-C8013RL

Product Name

5MP AI Dual Light Flateye Camera

Product Series

Q series

Product Type

Network Camera

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

5MP

Field of View

H: 97° / V: 53° / D: 113°

HD Recording

Yes

Lens Mount Type

M12-mount

Lens Type

Fixed

Maximum Aperture

f/1.2

Maximum Frame Rate

30 fps

Night Vision

Yes

Night Vision Type

Infrared/Color

Number of IR LEDs

1

Wide Dynamic Range

Yes

Camera

Night Vision Distance

30 m

Certifications

Ingress Protection Rating

IP66, IP67

RoHS Compliant

Compliant

Display & Graphics

Color Supported

Colour

Maximum Video Resolution

2592 x 1944

Environmental Conditions

Maximum Operating Temperature

60°C

Minimum Operating Temperature

-40°C

Operating Humidity

95%

Exposure

Longest Shutter Speed

1/5 Second

Minimum Illumination

0.022Lux

Shortest Shutter Speed

1/12000 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Focal Length

3.0 mm

Lens Included

Yes

Maximum Focal Length

3 mm

Physical Characteristics

Color

White

Color Family

White

Form Factor

Flateye

Weight (Approximate)

790 g

Product Information

Diameter

140 mm

Mount Type

Gang Box Mount

Storage

Recording Formats

SD

Storage Type

Memory Card

Miscellaneous

Environmental Certification

UL

Features

Anti-flicker, Automatic White Balance, Day/Night, Digital Noise Reduction, Gain Control, Intelligent Backlight Compensation (iBLC), Motion Detection, Privacy Masking, PTZ, SD Card Local Storage, Wide Dynamic Range

Impact Protection Rating

IK10

Indoor/Outdoor

Outdoor

Hanwha QNE-C8013RL 5MP H.265 IR IP Flateye Camera, 3.0mm Fixed Lens, WDR, WiseNR II, White
