General Information

ADI Part Number

02636-001

Brand Name

Axis Communications

Manufacturer

Axis Communications

Manufacturer Part Number

02636-001

Product Model

M4327-P

Product Name

M4327-P Panoramic Camera

Product Series

M43

Product Type

Panoramic Cameras

Technical Information

Connectivity Technology

Wired

Effective Camera Resolution

6MP

Field of View

Horizontal: 182°, Vertical: 182°

HD Recording

Yes

Lens Type

Fixed

Maximum Aperture

f/2.2

Maximum Frame Rate

60 fps

Wide Dynamic Range

Yes

Certifications

RoHS Compliant

Compliant

TAA Compliant

Yes

Display & Graphics

Color Supported

Colour

Maximum Video Resolution

2560 x 1920

Environmental Conditions

Maximum Operating Temperature

40°C

Minimum Operating Temperature

0°C

Operating Humidity

85%

Exposure

Longest Shutter Speed

1/5 Second

Minimum Illumination

0.16 lux|0.03 lux

Shortest Shutter Speed

1/33500 Second

Interfaces/Ports

Network (RJ-45)

Yes

Lens

Focal Length

1.1 mm

Lens Included

Yes

Maximum Focal Length

1.10 mm

Physical Characteristics

Color

White

Color Family

White

Form Factor

Fisheye

Height

51 mm

Weight (Approximate)

300 g

Product Information

Diameter

101 mm

Mount Type

Gang Box Mount, Junction Box Mount, Tripod Mount

Storage

Storage Type

Memory Card

Warranty

Limited Warranty

5 Year

Miscellaneous

Environmental Certification

EU RoHS, REACH, RoHS

Environmentally Friendly

Yes

Features

2D Noise Reduction, 3D Digital Noise Reduction, Day/Night, Human Detection, Mirror, Noise Reduction, Privacy Masking, Vehicle Detection, Video Management System, White Balance, Wide Dynamic Range

Indoor/Outdoor

Indoor

Package Contents

M4327-P Panoramic Camera
Installation guide
Owner authentication key

AXIS M4327-P M43 Series, 6MP IP Panoramic Camera, 1.1mm Fixed Lens, White
